Sophisticted RF Solutions for Radio Mics, Fibre & IEM/IFB

Wisycom design and build the most sophisticated RF solutions for radio microphones, IEM/IFB and presenter cues, radio talkback. They provide durable, flexible, reliable and practical products thanks to great attention to detail and ultimate quality.

We stock Wiscom radio mics, dual receivers, PSC receivers and their RF over fibre system. Please see details below of each individual part.

MTP41S is an extremely small and light pocket transmitter especially designed for professional wireless microphone applications. Very easy and quick to use thanks to OLED display, dedicated buttons and a joggle selector. MTP41S benefit also of the latest Wisycom RF technology along with an enhanced robustness against noise.

Wisycom MRK980 is a true diversity, ultra-wideband dual channel receiver. With its 1090MHz of band switching, it ensures the users an exceptional band flexibility, combined with a superb selectivity and intermodulation immunity, for best operating performances of the wireless microphone systems. MRK980 also features an internal DSP processor, Wisycom famous Multicompanding system, new Dante compatibility and a completely and renewed user interface, which make this system easy and quick to setup. MCR42 is a camera receiver designed for best-in-class performances. Four receivers are internally coupled by two in a real True Diversity Configuration. Its front end has a chain of microcontrolled-driven movable filters to allow Broadband Operation up to 240 MHz with great selectivity.A powerful low consumption DSP gives you the best of analogue and digital technologies in an hybrid approach for smooth operations, high coverage and with our patented PTT (push to talk) already integrated.

MAT244 & MAT288 are programmable diversity matrix combiners. These unique devices allows you to combine RF coming from 4 or 8 areas (a couple of diversity feed) on the fly thanks to a matrix of solid state switches. It is designed to have the greatest reliability, with redundant power supply (AC and DC). All operations can be remote with Ethernet. We also keep the full range of Wisycom antennas both active and passive, directional and omni. All of the active antennas can be controlled remotely from the MAT combiners and have inbuilt filters to try and shut out some the signals you don’t want and keep your radio mics squeaky clean.

MFL provides wideband optical link for up to 4 RF channels combined in a single fiber thanks to CWDM technology.
It is designed to allow for a flexible and modular configuration thanks to a mainboard that can be fitted with up to 4 plug-in boards that can be any combination of two types:

  • TX: Laser optical transmitter (CDWM) plug-in board
  • RX: Optical-receiver plug-in board

The Wisycom MTK952 Dual Channel IEM Transmitter Mono or Stereo is a versatile dual channel transmitter capable of working in a huge UHF bandwidth and of generating any kind of narrow-band modulations, with very high quality and low spurious emissions.Features:330 MHz Bandwidth (470-800 MHz)Direct Digital Synthesis (DDS) of signal for the highest flexibility and quality (> 70 dB stereo separation)Stereo, mono, intercom audio modulationDSP audio processing (40bit floating point / 2Gflops) with multi-compandingLow interference output stage with wideband intermodulation phase cancellation2400 user-defined frequencies (40 group by 60 freq.)Analogue & digital input (AES3)Output power up to 2 Watt (/W option)Redundant power supply 230/110 Vac & 12 VDC (DC is optional)SWR (Stationary Wave Ratio) sensing on antenna outputsReference In/Out for iso-frequency transmission (with option MS)DC OPTION:DC power supply (10-16VDC)MS OPTION:Master Slave configuration for iso-frequency network.
